GS Series Outdoor Transparent Curtain Screen:
GS 10 / GS 12 / GS 15 / GS 25 / GS 31 are beautiful aluminum frame design and beautiful shape, combine technology and art together,that is safe and stable. It is providing solutions for outdoor commercial square, commercial street, airports, museums, exhibitions, shopping malls, supermarkets,theaters, hotels, etc.
GS 25
The above specifications and photos are only for reference. We reserve all the right for the final explanation. Value GS 10
GS12 GS 15 GS 31 Pixel Pitch (mm) 10.4 12.5 15.625
25 31.25 Brightness ( nits ) 6500
7000 8000
7500 7000 Pixel Configuration SMD
DIP DIP
DIP DIP Colors 281 trillion
281 trillion
281 trillion
281 trillion 281 trillion Refresh Rate ( Hz ) >=2000
>=2000
>=2000
>=2000
>=2000
Pixel Matrix Per Panel 94 x 48
40 x 80
32 x 64
20 x 60 16 x 48 Pixel Matrix Per Sq.m1
9216 6400 4096 1600 1024 Viewing Angle (H/V) 120 / 60
100 / 60
100 / 60
100 / 60 100 / 60
Power Consumption (Max / W) 780 / 260 w/sq.m 480 / 160 w/sq.m
400 / 130 w/sq.m 375 / 125 w/sq.m 300 / 100 w/sq.m IP Rate IP67 / IP67
IP67 / IP67
IP67 / IP67
IP67 / IP67 IP67 / IP67
Input Voltage (AC) 110/220
110/220
110/220
110/220 110/220 Panel Size ( L x W x H ) 500 x 1000 x 101 mm
500 x 1000 x 105 mm
500 x 1000 x 107 mm
500 x 1500 x 107 mm 500 x 1500 x 107 mm Panel Weight
13 (Alu.) 11 (Alu.)
10.5 (Alu.)
12 (Alu.)
9.7 (Alu.)
Ultra-light design The cabinet is ultra-light, only 9.7-13kg per cabinet. |
|
New single light bar (Independent plug and pull technology) Solve the problem of signal and electrical synchronous transmission so the maintenance is more convenient and fast. | |
Unique heat sink design Speed up the heat conduction so that LED mesh is stable operation. |
|
Strong Tail board design Quick mounting clip foot, safe and fast, ensure flatness. |
|
P67 high protection Improve product stability. |
|
Font & Black Service Easier and faster maintenance. |
|
Applications Outdoor Commercial Square, Commercial Street, Airports, Museums,Exhibitions, Shopping Malls, Supermarkets, Theaters, Hotels, etc. |
|
Product Installation
